Harmsco Hurricane 40 Housing 50 gpm HUR40HP

Regular price
$3,765.00
Sale price
$3,765.00
Shipping & Returns calculated at checkout.

Application: Cyclone Separation Single Cartridge Housing for Heavy Solids Removal

Two technologies in one - cyclone separation in the outer chamber to siphon out large particles of solids followed by finer filtration in the inner chamber.

A wide range of cartridges to choose from; from 0.35 microns all the way up to 150 microns.  Hurricane housings are available in three sizes:

  • HUR40HP - up to 50 gpm
  • HUR90HP - up to 100 gpm
  • HUR170HP - up to 150 gpm

Features:

  • Combination cyclone separator and cartridge filter in a single compact design
  • Patented Up-flow design with tangential entry which prevents air entrapment
  • CPVC standpipe (standard) - stainless steel optional
  • NSF 61 listed
  • Temperature rated to 140 degrees F.
  • Pressure rated up to 150 psi
  • 2 inch inlet and outlet connections; 1 inch drain connection
  • Fail-safe closure system

Spec Sheets:
